OPEN-TYPE HIGH-SPEED PRECISION PRESS(THREE ROUND PILLAR TYPE) 25T-80Tons
keywords:
Category:
OPEN-TYPE HIGH-SPEED PRECISION PRESS(THREE ROUND PILLAR TYPE)
Unique Performance and Characteristics
● High-rigidity integrated casting body heavy-duty structural design: using dynamic mechanical analysis and structural simulation to exceed 25% capacity design, optimization, and the best perfect structural combination.
● Adopting three-circle guide column structure transmission technology, the transmission precision is more stable and the precision is higher.
● High precision and stability: It adopts international leading casting, processing and other manufacturing industries to ensure high strength, wear resistance and stability.
● Safe and secure: It adopts dual-loop safety protection design and is equipped with international cutting- edge brand electrical components.
● Durability: It has the functions of self-detection, alarm, self-protection, etc., which greatly improves the service life of the machine.
● Intelligence and automation: Based on the actual needs of customers, we have developed a unique automatic program control system and configured a microcomputer operating system with powerful functions.
● Environmental protection, energy saving: The best rigid combination has low friction loss and low noise, and is equipped with high-torque energy-saving motors and inverters.
Standard Configuration
Taiwan Shihlin Frequency converter | Mobile Operator Station |
Taiwan TECO Main Motor | Stand-alone electric control box |
Japan Showa Hydraulic overload protection | Blowing device |
Taiwan ISHAN Automatic Lubrication System | Air Interface |
Taiwan Delta Microcomputer operating system | Forward and reverse mechanism of main motor |
Japan Fuji Two-handed operation | Lockable switch |
France Schneider Electrical Element | Heavy Duty shock-proof Pin |
Japan TOYOOK Brake Double Valve | Microcomputer operating system |
Taiwan AIRTAC Pneumatic Element | Pre-cutting device |
Forced thin oil lubrication system | Presetting device |
Double Circuit Safety Protection | Production counting function |
Automatic reserved port | Detection device for material misdelivery |
Digital mode high display instrument | Pressure detection function |
Electronic Cam switch | Mould lamp |
Travel Angle indicator | Repair Tools and tool kit |
Independent mobile electric control box | Instruction Manual |
Optional Configuration
● Air-pressure type die cushion device
● Upper slide feeding device
● Quick-change die
● Mould lifter, mould shifting arm, mould clamping device
● Wet Clutch
● Photoelectric protection device
● Mobile operating platform
● Feeding Machine
● Leveling machine
● Material Rack
● Three-in-one feeder
● German SERVO control system
● Industrial control system for Internet of things
Specifications
Specification | Unit | XTHA-25 | XTHA-45 | XTHA-60 | XTHA-80 | ||||
Mode |
| A | B | A | B | A | B | A | B |
Capacity | Ton | 25 | 45 | 60 | 80 | ||||
Stroke Length | mm | 30 | 30 | 30 | 30 | ||||
Stroke per minute | s.p.m | 200-600 | 200-800 | 200-500 | 200-700 | 200-400 | 200-600 | 200-300 | 200-500 |
Die Height | mm | 210 | 230 | 305 | 330 | ||||
Bolster | mm | 600×300×80 | 700×415×100 | 840×470×105 | 100×600×110 | ||||
Area of slide | mm | 300×205 | 420×320 | 550×340 | 580×450 | ||||
Slide adjustment | mm | 30 | 30 | 30 | 30 | ||||
Bed opening | mm | 200×100 | 240×120 | 320×160 | 600×110 | ||||
Motor | kw | 3.7 | 5.5 | 7.5 | 11 | ||||
Grpss weight | kg | 3000 | 4500 | 8000 | 13000 | ||||
Lubrication | Forceful Autom ation | Forceful Autom ation | Forceful Autom ation | Forceful Autom ation | |||||
Speed cpntrol | Inverter | Inverter | Inverter | Inverter | |||||
Clutch@brake | Air@Friction | Air@Friction | Air@Friction | Air@Friction | |||||
Auto top stop | Standard | Standard | Standard | Standard | |||||
Vlibration system | Optional | Optional | Optional | Optional | |||||
Product application industry
Automotive Industry
Appliance Manufacturing
Electronics Industry
Hardware & Tools
Aerospace Components
